1000L Customized Liquid Washing Homogenizer Shampoo Detergent Mixer Two Pots
Quick Detail:
We are manufacturer for vacuum mixer making 20 years with factory based on Yangzhou province. It is indispensable equipment to paste honey and is very useful experience tool in cosmetic factory with complete function and high quality. Vacuum homogenizing emulsifier means that when the materials are under the vacuum condition, it makes use of the high shear emulsifier to distribute one or several phases to another continuous phase rapidly and evenly. The materials will be processed in the narrow space between stator and rotor by strong energy of motion produced by the mechanical effect. By the operation of hydraulic shearing, centrifugal extruding, impacting, breaking and turbulence for over 100 thousand times per minute, the materials will be dispersed and emulsified instantly and evenly. After reciprocating circulation at high quality without bubbles will be achieved.
1. One-way stirring
2. Mixing Power: 2.2-4KW
3. Bottom homozenizer
4. Half-open cover
5. Steam heating or electric heating
6. Button control
7. With work stair
8. CE,ISO,GMP compliant
9. Online support Video technical support
10. One-year warranty
Applications:
Widely used in producing liquid washing products like bath shower, dish washing, hand washing, lotion, liquid soap, detergent, gel etc.
Complex scraping board blending oar is suitable to every kind of complicated recipe.
Description:
The all-round wall scraping mixing adopts the frequency converter for speed adjustment, so that high quality products of different processes according to customer requirements.
The pot body is welded by imported three-layer stainless steel plate. The tank body and the pipes adopt mittor polishing, which fully conforms to GMP requirements.According to customer requirement, the tank can heat and cool materials.
The heating way including steam heating and electric heating. Easy to discharge , bottom direct discharge or by transfer pump.
Specifications:
| Specification | Volume | Blending power (kw) | Blending rotation speed (r/min) | Homozenizing speed (r/min) | Homozenizing rotation speed (r/min) | Heating way |
| JBJ-200 | 200 | 1.5 | 0~65 | 3 | 3000 | Steam or electric |
| JBJ-500 | 500 | 2.2 | 0~65 | 4 | 3000 | Steam or electric |
| JBJ-1000 | 1000 | 2.2-4 | 0~65 | 7.5 | 3000 | Steam or electric |
| JBJ-1500 | 1500 | 4-5.5 | 0~65 | 11 | 3000 | Steam or electric |
| JBJ-2000 | 2000 | 5.5 | 0~53 | 11 | 3000 | Steam or electric |
| JBJ-3000 | 3000 | 7.5 | 0~53 | 15 | 1500 | Steam or electric |
| JBJ-5000 | 5000 | 11 | 0~53 | 22 | 1500 | Steam or electric |
Characteristic:
1. Function : heating, blending, homogenizing
2. Mixing system : frame scraper agitator mixer and high shear homogenizer mixer
3. Heating system : jacket heating / running water cooling
4. Movable design and simple to operate
Feature:
1.The mixing tank is made of all stainless steel materials. Its inner wall is made of high-quality 316L stainless steel (The part in contact
with the material). The tank and pipe are mirror polished. Complying with GMP requirements and specifications.
2.The equipment consists of a stainless steel electric control cabinet and a main pot. The whole machine has a compact structure and
it is easy to operate.
3. You can configure heating pot and cooling pot separately according to actual requirements. The materials can be heated or cooled according to process requirements. The heating method can be steam heating or electric heating.
4. There are various types of durable agitator blade, with strong mixing strength. It is suitable for the production of different products.
5. The motor is equipped with an advanced frequency converter, which can adjust the stirring speed according to production requirements.
6. You can choose to configure a AES dissolver to accelerate material dissolution and emulsification. It can save time and labor for you.
7. The stainless steel electric control cabinet can comprehensively monitor its operation, and it can display data, such as temperature and stirring speed, etc.
8. It can be equipped with vacuum pump for vacuum bubble extraction (optional).
FAQ:
Q1: I am not in China ,how can i know your quality?
A: We have a factory with 20 years, we have much experience to help our customers business better.
Q2: how can we guarantee quality?
A: Always a pre-production sample before mass production. Always final Inspection before shipment.
Q3: what can you buy from us?
A: Vacuum Homogeneous Emulsifying Machine/Homogenizing Mixer/Reverse Osmosis Water Treatment Machine/Automatic and Semi Automatic Filling Machine/Perfume Machine
Q4: why should you buy from us not from other suppliers?
A: APVO company aims to build high quality, high efficiency, high performance equipment, stick to Science-First,People-oriented principles.We have the first-class after-sale service team and gain the customer's recognition.
